High combination rate steel clad copper clad steel with high performance cost ratio and high strength
Steel clad copper clad steel belongs to the combination of non-ferrous metal and steel. It has superior properties in life cycle, cost , strength and so on. ZEGOTA develop and produce high quality Steel clad copper clad steel with leading high strength, low cost and high bonding rate clad metal by virtue of innovative technology, high-end equipment and high-quality raw materials.
Advantages:
1. High combination rate: We make clad metal by cold rolling technology, then the combination rate can improve 30% at least compared with welding combination and explosion combination.
2. High performance cost ratio: It is low manufacturing cost by clad in physical process and unique cold rolling technology without extra welding and explosion.
3. High strength: Using unique clad technology and taking advantage of the high strength of steel, while copper is soft, the combination of the two can make full use of its advantages include of the high strength of steel and electric conductivity and magnetic conductivity of copper.
Parameters:
| Clad material |
Steel |
Steel |
Steel |
| Copper |
Copper |
Copper |
| Steel |
Steel |
Steel |
| Thickness(mm) |
0.01-4.0 |
0.04-4.0 |
0.01-4.0 |
| Width(mm) |
5.0-1500 |
5.0-1500 |
5.0-1500 |
| Tensile strength(MPa) |
260-320 |
480-580 |
480-580 |
| Yield strength(MPa) |
200-260 |
300-380 |
300-380 |
| Elongation(%) |
≥37 |
≥15 |
≥15 |
Application:
1. Military industry: Steel clad copper clad steel is used to replace the shell made of traditional steel and copper, which not only guarantees the original performance, but also has the characteristics of corrosion resistance and good surface lubrication.
2. Electronic industry: There are many gaskets in electronic components, which are strong and thin. Steel clad copper clad steel can meet the design requirements of various shapes and functions.
3. Cookware industry: Steel clad copper clad steel has good strength and plasticity, which greatly improves the processing efficiency of products. Copper has good magnetic conductivity, which can improve the heating efficiency and uniformity of pots.
